Alternators

AC Generator 5 to 90kVA

FEATURES
  • Compact and aesthetically built.
  • Conforms to all leading industrial and marine standards.
  • Simple design, fewer parts easy access to coupling bolts, output terminals and rotating diodes.
  • Simple to install and maintain.
  • Wide range of flange adopters and single bearing flexi-disc couplings.
  • Wound with 2/3 pitches in stator to eliminate harmonics.
  • Sophisticated and reliable AVR, having good capability to handle non-linear loads.
  • Self lubricating, sealed type for ball bearing.
  • Paralleling operation facility is optional in frame 4AB200 & 4AB225.
SPECIFICATIONS
  • Phase
  • : Three / Single
  • Frequency, Hz
  • : 50
  • Voltage, V
  • : 415/240
  • Power factor, lag
  • : 0.8
  • Ambient
  • : 40 deg.c
  • Altitude
  • : <1000 mtrs.
  • Speed, rpm
  • : 1500
  • Mounting
  • : Horizontal foot mounted
  • Duty
  • : Continuous
  • Direction of rotation
  • : Clockwise from de
  • Automatic voltage regulator
  • : M/c mounted
  • Voltage regulation
  • : +/-1% with 4% prime mover speed variation
  • Standards
  • : IS 4722 -1992, IEC 34
  • Class of insulation
  • : H
  • Temperature rise
  • : H
  • Enclosure
  • : IP 20
  • Cooling
  • : IC 01
  • Wave form distortion (thd)
  • : Less than 3%
  • Overload capacity
  • : 10% overload for 1hr. once in 12 hrs.
  • Unbalance permitted
  • : 25% with none of the phase currents exceeding the rated current. Temp rise limits for corresponding class of insulation may exceed 10 degre c under such cond. voltage regulation under above condition will not apply.
  • No. of bearings
  • : Single /Double
  • Lubrication type
  • : Grease Lubricated

Brushless E-Series

FEATURES
  • Compact and aesthetically built.
  • Conforms to all leading standards.
  • Simple design, fewer parts, easy access to coupling bolts, output terminals.
  • Simple to install and maintenance.
  • Popular range of flange adaptors & flexi disc coupling.
  • Wound with 2/3rd pitch in stator to eliminate harmonics.
  • Sophisticated & reliable AVR.
SPECIFICATIONS
  • Phase
  • : Three / Single
  • Frequency, Hz
  • : 50
  • Voltage, V
  • : 415/240
  • Power factor, lag
  • : 0.8
  • Ambient
  • : 40 deg.c
  • Altitude
  • : <1000 mtrs.
  • Speed, rpm
  • : 1500
  • Mounting
  • : Horizontal foot mounted
  • Duty
  • : Continuous
  • Direction of rotation
  • : Clockwise from de
  • Automatic voltage regulator
  • : M/c mounted
  • Voltage regulation
  • : +/-1% with 4% prime mover speed variation
  • Standards
  • : IS 4722 -1992, IEC 34
  • Class of insulation
  • : H
  • Temperature rise
  • : H
  • Enclosure
  • : IP 20
  • Cooling
  • : IC 01
  • Wave form distortion (thd)
  • : Less than 3%
  • Overload capacity
  • : 10% overload for 1hr. once in 12 hrs.
  • Unbalance permitted
  • : 25% with none of the phase currents exceeding the rated current. Temp rise limits for corresponding class of insulation may exceed 10 degre c under such cond. voltage regulation under above condition will not apply.
  • No. of bearings
  • : Single /Double
  • Lubrication type
  • : Grease Lubricated

Alternators

AC Generator 5 to 90kVA

FEATURES
  • Self-excited, self-regulated unity power factor AC generator.
  • Horizontal foot mounted in SPDP enclosure with two bearings.
  • Series compounding type of excitation.
  • Aesthetically designed.
  • Class “F” Insulation.
  • Voltage regulation is maintained within ±10%.
  • Guaranteed voltage buildup
SPECIFICATIONS
  • Phase
  • : Three / Single
  • Frequency, Hz
  • : 50
  • Voltage, V
  • : 415/240
  • Power factor, lag
  • : UPF
  • Ambient
  • : 40 deg.c
  • Altitude
  • : <1000 mtrs.
  • Speed, rpm
  • : 1500
  • Mounting
  • : Horizontal foot mounted
  • Duty
  • : Continuous
  • Direction of rotation
  • : Clockwise from de
  • Automatic voltage regulator
  • : M/c mounted
  • Standards
  • : IS 4722 -1992, IEC 34
  • Class of insulation
  • : F
  • Temperature rise
  • : F
  • Enclosure
  • : IP 20
  • Cooling
  • : IC 01
  • No. of bearings
  • : Two
  • Lubrication type
  • : Grease Lubricated
